System Hardware
|
| Chipset |
Intel® 6th~13th Gen Core Processor |
Watchdog |
0-255 seconds/classification is realized by system software |
| Ram |
4GB DDR4L memory, up to 64GB(12th/1 3th CPU) |
Power Supply |
1*3Pin Phoenix DC connector, support 9-36Vwide voltage DC lN |
| Hardware monitor |
Voltage and CPU temperature monitoring |
| OS |
| OS |
Windows 10、WES 10、Linux |
| l/O Ports |
| USB |
2*USB 2.0+4*USB 3.0 |
Display |
1*VGA、1*HDMI |
| COM |
6*RS232 (optional 4*RS485/RS422) |
MiniPCIE |
2*MINI PCle (WIF/BT/4G) |
| Ethernet |
2*Intel®GbE RJ45 1000M |
Buttons |
1 x Power+1 x Reset+1 x Clear CMOS Button |
| GPIO |
7 input7 output |
Environment
|
| Vibration Protection |
5-19Hz/1.0mm amplitude; 19-200Hz/1.0gacceleration |
Operating Temp. |
-20℃~60℃, with air flow |
| Shock Protection |
acceleration 10g/1 1ms |
Storage Temp. |
-30℃~70℃ |
| Reliability |
MTBF≥50000h; MTTR<0.5h |
Humidity |
90% @30℃ non-condensing |
Mechanical
|
Dimension (WxHxD
|
249 x 150 x86 mm |
Material |
Auminum alloy fanless design |
| Weight |
2.2kg |
Color |
Black |
