| System Hardware |
|||
| CPU | MTK MT6771 0cta-core 2.0GHz | Earpiece | Waterproof earpiece |
| Memory | 4GB. Max 8GB Ram | Button | Power button.Volume +/-. 1*Customize function key 1*Barcode scanner shortcut key |
| Storage | 64GB. Max 128GB Rom | ||
| Camera | 5MP front camera with fixed focus 13MP rear camera with auto focus and LED light |
||
| Speaker | Dual speakers, 1.2W8Ω | LED Indicator | Charging indicator |
| MIC | Dual MlC | Sensor | G-sensor,Gyroscope,E-compass, Distance sensor, Motor, Light sensor |
| Display | |||
| LCD Type | 10.1" TFT-LCD | Luminance | 300 cd/m2,Optional 800/1000 cd/m2 |
| Max.Resoltuion | 1280*800 Optional 1920*1200 800cd/m2 | Touchscreen | 5-Points capacitive touch screen Optional AG+AF Or AG+AF+Wet Hand/Glove |
| OS | |||
| OS | Android 10 OS with GMS certificate | ||
| l/O Interface | |||
| POGO PIN | 1*POGO PIN(USB+Charging) | ||
| USB | 1*USB Type C(USB OTG+Charging) 1*USB 2.0, TYPE A |
||
| Video | 1*mini HD | SlM Card Slot | 1*Micro SlM Card Slot |
| Audio | 3.5mm Headphone Jack | TF Card Slot | 1*TF Card Slot, up to 256GB |
| Ethernet | 1*RJ45 | ||
| Communication | |||
WNAN |
GSM: B2/B3/B5/B8 WCDMA: B1/B2/B5/B8 CDMA2000 LTE-FDD: B1/B2/B3/BB5/B7/B8/B20/B28,A/B28B.B12/B 13/B14/B66/B71 LTE-TDD:B38/B39/B40/B41 |
WIFI | 802.11a/b/g/n/ac, 2.4G+5.8G Dualband WIFI |
| Bluetooth | Bluetooth v2.1+EDR/V3.0+HS/V4.1 LE | ||
| GNSS | MT6631 GPS+BD+GLonass/Galleo | ||
| Extended Functions | |||
| NFC | 13.56Mhz ,support 144 43A/14443B/15693 | ID Card Recognition | Optional lD card recognition module |
| RFID | Optonal RFID/HF RFID/UHF RFID | Barcode Scanner | Optional 1D/2D barcode scanner, 2 choose 1 |
| Power | |||
| Power Input |
5V DC Input.5V/3A power adapter Optional 5-24v DC power input, no built-in battery power supply |
Battery | 10000mAh.3.8v Li-lon battery |
| Battery Life | 10 hours (Play 1080P video under LCD 50% backlight) |
||
| Environment |
|||
| Drop | 1.2m free fall to the wooden floor | Operating Temp. | -10℃~50℃ |
| IP Rating | IP67 | Storage Temp. | -30℃~70℃ |
| Certificate | |||
| Certificate | CE、ROHS、UN38.3、MSDS、IEC62133 | ||
| Mechanical |
|||
| Dimension (WxHxD |
275*179.2*21.8mm | ||
| Weight | 1.25kg | Color | Black |
| Accessory | |||
| Accessory | Hand strap, 5V/3A power adapter | ||
| Optional Accessory | Ofice docking, Vehicle stand, Vehicle charger, Passive stylus pen, Type-C data cable, Type-C OTG cable, USB-DC cable | ||
